Smooth

The Smooth brush straightens and smooths bent and kinked fibers. The effect is similar to aligning all points into a straight line between the root and tip of each individual fiber. The Fur brush can be combined with the Customizing Paint Tools to further customize how the brush styles the fur. The Smooth tool can be found in the Hair Tools sub-tab of the toolbox, found in the Paint tab of the interface. When selected, the following attributes display in the Properties panel.

Original   Push

On the left, a group of combed guides, on the right the Smooth tool applied.

Sculpt Mask

Option

Description

Smooth Amount

The Smooth Amount value determines the strength of the brush stroke. Higher values have a greater influence over the fibers than lower values.

Edit Fur Map

You can style fur by way of a Fur Vector Map, providing a means to control combing direction and length with an image map, producing very detailed results. All that is necessary is a Fur Layer in the Shader Tree and a Floating Point image (such as EXR) with the layer effect set to Fur Vector. Generally, the fur styling tools are meant to edit Guides, in order to edit the associated fur map, you need to enable the Edit Fur Map option.

Screen Brush

The Screen Brush option, enabled by default, affects all vertices under the brush tips circle, regardless of their distance. When the option is disabled, only vertices that are within the 3D sphere of influence around the brushes tip are affected.
